V23057-A0006-A101 RELAY POWER 5A 24VDC GEN PURPOSE SPDT TE

V23057-A0006-A101 RELAY POWER 5A 24VDC GEN PURPOSE SPDT TE Description

V23057-A0006-A101 RELAY POWER 5A 24VDC GEN PURPOSE SPDT TE V23057-A0006-A101 is a reliable and efficient general relay that designed for N/A applications with a contact voltage of 250VAC/30VDC and coil resistance of 1.20K Ohms. Features a coil power of 480mW and operates within a temperature range of -40°C~+70°C.Compact design with dimensions: length 28.00mm, width 25.00mm, and height 10.80mm.Manufactured by TE CONNECTIVITY and compliant with ROHS standards. Packaged as TUBE for convenience.

V23057-A0006-A101 RELAY POWER 5A 24VDC GEN PURPOSE SPDT TE Technical Specifications

• Manufacturer: TE CONNECTIVITY
• RelayType: Relay Power
• Series: V23057
• MountingType: THT
• ContactForm: SPDT (1 Form C)
• CoilType: Non Latching
• ContactCurrent(Nom): 5A
• ContactCurrent(Max):
• CoilVoltage: 24VDC
• CoilCurrent: 20mA
• ContactVoltage: 250VAC/30VDC
• CoilResistance: 1.20K Ohms
• CoilPower: 480mW
• OperatingTemperature: -40°C~+70°C
• NumberofPins: 5 Pin
• Length: 28.00mm
• Width: 25.00mm
• Height: 10.80mm
• Rohs: ROHS
• Packaging: TUBE

---

You can click for product datasheet.
