TX2SS-3V RELAY 46.7mA 3VDC TELECOM TYPE

TX2SS-3V RELAY 46.7mA 3VDC TELECOM TYPE Description

TX2SS-3V RELAY 46.7mA 3VDC TELECOM TYPE TX2SS-3V is a reliable and efficient general relay that designed for N/A applications with a contact voltage of 220VDC - Max and coil resistance of 64.30 Ohms. Features a coil power of 140mW and operates within a temperature range of -40°C~+85°C.Compact design with dimensions: length 15.00mm, width 7.40mm, and height 8.20mm.Manufactured by PANASONIC COMP. and compliant with ROHS standards. Packaged as TUBE for convenience.

TX2SS-3V RELAY 46.7mA 3VDC TELECOM TYPE Technical Specifications

• Manufacturer: PANASONIC COMP.
• RelayType: Relay Telecom
• Series: TX
• MountingType: SMT
• ContactForm: DPDT (2 Form C)
• CoilType: Non Latching
• ContactCurrent(Nom): 2A
• ContactCurrent(Max):
• CoilVoltage: 3VDC
• CoilCurrent: 46.70mA
• ContactVoltage: 220VDC - Max
• CoilResistance: 64.30 Ohms
• CoilPower: 140mW
• OperatingTemperature: -40°C~+85°C
• NumberofPins: 8 Pin
• Length: 15.00mm
• Width: 7.40mm
• Height: 8.20mm
• Rohs: ROHS
• Packaging: TUBE

---

You can click for product datasheet.
