PL003 RELAY 2A 3VDC DPDT 2 FORM C LATCHING TYPE

PL003 RELAY 2A 3VDC DPDT 2 FORM C LATCHING TYPE Description

PL003 RELAY 2A 3VDC DPDT 2 FORM C LATCHING TYPE PL003 is a reliable and efficient general relay that designed for N/A applications with a contact voltage of 30VDC and coil resistance of 90 Ohms. Features a coil power of 100mW and operates within a temperature range of -40°C~+85°C.Compact design with dimensions: length 14.30mm, width 9.30mm, and height 5.00mm.Manufactured by HUAGUAN and compliant with ROHS standards. Packaged as BOX for convenience.

PL003 RELAY 2A 3VDC DPDT 2 FORM C LATCHING TYPE Technical Specifications

• Manufacturer: HUAGUAN
• RelayType: Relay General
• Series:
• MountingType: THT
• ContactForm: DPDT (2 Form C)
• CoilType: Latching, Single Coil
• ContactCurrent(Nom): 1A
• ContactCurrent(Max): 2A
• CoilVoltage: 3VDC
• CoilCurrent:
• ContactVoltage: 30VDC
• CoilResistance: 90 Ohms
• CoilPower: 100mW
• OperatingTemperature: -40°C~+85°C
• NumberofPins: 10 Pin
• Length: 14.30mm
• Width: 9.30mm
• Height: 5.00mm
• Rohs: ROHS
• Packaging: BOX

---

You can click for product datasheet.
