ORWH-SH-124D1F,000 RELAY 10A 24VDC SPDT THT OEG

ORWH-SH-124D1F,000 RELAY 10A 24VDC SPDT THT OEG Description

ORWH-SH-124D1F,000 RELAY 10A 24VDC SPDT THT OEG ORWH-SH-124D1F,000 is a reliable and efficient general relay that designed for N/A applications with a contact voltage of 277VAC/28VDC - Max and coil resistance of 1.60K Ohms. Features a coil power of 360mW and operates within a temperature range of -30°C~+70°C.Compact design with dimensions: length 19.00mm, width 15.50mm, and height 15.80mm.Manufactured by TE CONNECTIVITY and compliant with ROHS standards. Packaged as TUBE for convenience.

ORWH-SH-124D1F,000 RELAY 10A 24VDC SPDT THT OEG Technical Specifications

• Manufacturer: TE CONNECTIVITY
• RelayType: Relay General
• Series: ORWH
• MountingType: THT
• ContactForm: SPDT (1 Form C)
• CoilType: Non Latching
• ContactCurrent(Nom): 10A
• ContactCurrent(Max):
• CoilVoltage: 24VDC
• CoilCurrent: 15mA
• ContactVoltage: 277VAC/28VDC - Max
• CoilResistance: 1.60K Ohms
• CoilPower: 360mW
• OperatingTemperature: -30°C~+70°C
• NumberofPins: 5 Pin
• Length: 19.00mm
• Width: 15.50mm
• Height: 15.80mm
• Rohs: ROHS
• Packaging: TUBE

---

You can click for product datasheet.
