HF32FA-G/012-HSL1(335) RELAY SPST-NO; Ucoil: 12VDC; 16/250VAC

HF32FA-G/012-HSL1(335) RELAY SPST-NO; Ucoil: 12VDC; 16/250VAC Description

HF32FA-G/012-HSL1(335) RELAY SPST-NO; Ucoil: 12VDC; 16/250VAC HF32FA-G/012-HSL1(335) is a reliable and efficient general relay that designed for N/A applications with a contact voltage of 250VAC - Max and coil resistance of 320 Ohms. Features a coil power of 230mW and operates within a temperature range of -40°C~+85°C.Compact design with dimensions: length 17.60mm, width 10.10mm, and height 12.70mm.Manufactured by HONGFA and compliant with ROHS standards. Packaged as BOX for convenience.

HF32FA-G/012-HSL1(335) RELAY SPST-NO; Ucoil: 12VDC; 16/250VAC Technical Specifications

• Manufacturer: HONGFA
• RelayType: Relay Power
• Series: HF32FA-G
• MountingType: THT
• ContactForm: SPST-NO (1 Form A)
• CoilType: Non Latching
• ContactCurrent(Nom): 10A
• ContactCurrent(Max):
• CoilVoltage: 12VDC
• CoilCurrent:
• ContactVoltage: 250VAC - Max
• CoilResistance: 320 Ohms
• CoilPower: 230mW
• OperatingTemperature: -40°C~+85°C
• NumberofPins: 4 Pin
• Length: 17.60mm
• Width: 10.10mm
• Height: 12.70mm
• Rohs: ROHS
• Packaging: BOX

---

You can click for product datasheet.
