DSP1A-L-DC3V RELAY POWER 8A 3VDC 1FormA PANASONIC

:
Product Code : o386109
: T531311
2.4467 USD + VAT
Price Alert
Featured Information
DSP1A-L-DC3V RELAY POWER 8A 3VDC 1FormA PANASONIC
2.4467 USD + VAT
Buy MORE, Pay LESS
Quantity
Discount
1 - 49
%0
50 - 99
%12
100 - 200
%18

DSP1A-L-DC3V RELAY POWER 8A 3VDC 1FormA PANASONIC


DSP1A-L-DC3V RELAY POWER 8A 3VDC 1FormA PANASONIC Description


DSP1A-L-DC3V RELAY POWER 8A 3VDC 1FormA PANASONIC DSP1A-L-DC3V is a reliable and efficient general relay that designed for N/A applications with a contact voltage of 250VAC/30VDC and coil resistance of 60 Ohms. Features a coil power of 150mW and operates within a temperature range of -40°C~+60°C.Compact design with dimensions: length 20.20mm, width 11.00mm, and height 10.50mm.Manufactured by PANASONIC COMP. and compliant with ROHS standards. Packaged as BULK for convenience.

DSP1A-L-DC3V RELAY POWER 8A 3VDC 1FormA PANASONIC Technical Specifications


  • Manufacturer: PANASONIC COMP.
  • RelayType: Relay Power Polarized
  • Series: DSP
  • MountingType: THT
  • ContactForm: SPST-NO (1 Form A)
  • CoilType: Latching, Single Coil
  • ContactCurrent(Nom): 8A
  • ContactCurrent(Max):
  • CoilVoltage: 3VDC
  • CoilCurrent: 50mA
  • ContactVoltage: 250VAC/30VDC
  • CoilResistance: 60 Ohms
  • CoilPower: 150mW
  • OperatingTemperature: -40°C~+60°C
  • NumberofPins: 4 Pin
  • Length: 20.20mm
  • Width: 11.00mm
  • Height: 10.50mm
  • Rohs: ROHS
  • Packaging: BULK

  • You can click for product datasheet.
