HX035M221F12PKKKS00A CAP.EL.220uF 35V 8x12 3.5MM 105C 9000H AEC-Q200 TH

HX035M221F12PKKKS00A CAP.EL.220uF 35V 8x12 3.5MM 105C 9000H AEC-Q200 TH Description

HX035M221F12PKKKS00A CAP.EL.220uF 35V 8x12 3.5MM 105C 9000H AEC-Q200 TH The HX035M221F12PKKKS00A is a high-quality product offering CAP.EL.220uF 35V 8x12 3.5MM 105C 9000H AEC-Q200 TH. With a shrink ratio of N/A and -40°C~+105°C operating temperature, it provides reliability in various applications.

HX035M221F12PKKKS00A CAP.EL.220uF 35V 8x12 3.5MM 105C 9000H AEC-Q200 TH Technical Specifications

• Manufacturer: SUSCON
• Features:
• CapacitorType: Electrolytic
• Series: HX
• MountingType: THT
• Package/Case: Radial
• Polarization: Polar
• Capacitance: 220uF
• VoltageRating: 35VDC
• Tolerance: ±20%
• LeadSpacing: 3.50mm
• LeadForm:
• RippleCurrent: 1.28A
• ESR Frequency:
• Impedance Frequency:
• Lifetime Temperature: 9000 Hrs @ 105°C
• Applications: Automotive(AEC-Q200)
• Diameter: 8.00mm
• Length: 12.00mm
• Width:
• Height:
• OperatingTemperature: -40°C~+105°C
• ROHS: ROHS
• Packaging: AMMO PACK
• ShrinkRatio:

---

You can click for product datasheet.
