HX025M332K20PE99S00A CAP.EL.3300uF 25V 18x20 7.5MM 105C 10000H AEC-Q200

HX025M332K20PE99S00A CAP.EL.3300uF 25V 18x20 7.5MM 105C 10000H AEC-Q200 Description

HX025M332K20PE99S00A CAP.EL.3300uF 25V 18x20 7.5MM 105C 10000H AEC-Q200 The HX025M332K20PE99S00A is a high-quality product offering CAP.EL.3300uF 25V 18x20 7.5MM 105C 10000H AEC-Q200. With a shrink ratio of N/A and -40°C~+105°C operating temperature, it provides reliability in various applications.

HX025M332K20PE99S00A CAP.EL.3300uF 25V 18x20 7.5MM 105C 10000H AEC-Q200 Technical Specifications

• Manufacturer: SUSCON
• Features:
• CapacitorType: Electrolytic
• Series: HX
• MountingType: THT
• Package/Case: Radial
• Polarization: Polar
• Capacitance: 3300uF
• VoltageRating: 25VDC
• Tolerance: ±20%
• LeadSpacing: 7.50mm
• LeadForm:
• RippleCurrent: 2.85A
• ESR Frequency:
• Impedance Frequency:
• Lifetime Temperature: 10000 Hrs @ 105°C
• Applications: Automotive(AEC-Q200)
• Diameter: 18.00mm
• Length: 20.00mm
• Width:
• Height:
• OperatingTemperature: -40°C~+105°C
• ROHS: ROHS
• Packaging: AMMO PACK
• ShrinkRatio:

---

You can click for product datasheet.
